Tablet Hardness Tester

Portable Tablet Hardness Tester

4.8 / 5 · 37 verified reviews

Model : µTHCal10 | Make : ANALAB | HSN Code : 90248091

A compact size and high accuracy instrument to measure the tablet Hardness with LCD backlit display showing hardness range 5 to 500N, having measurable units i.e. N, KGF, Lbf. External RS-232 printer attachment facility available.

Features:
  • Tablet Hardness Tester with printer connectivity
  • Complies with USP requirements
  • Hardness measurement by load cell upto 500N
  • Printer connectivity through RS 232 port
  • Programmable plausibility upper (T1) and lower (T2) tolerance limits
  • Display and print-out of 10 test values and with statistics
  • Tester operates on rechargeable battery

Share:
Main Load
0.1N
Accuracy
0.5% Full Scale
Tablet Size
2 mm to 28 mm
Power
Ni-Hi 8.4V, 1200mA
Optional Power
6 VDC Adaptor
Carry Temperature
27°C / 70°C
Relative Humidity
80% ±5% RH
Work Environment
No Vibrancy
Dimension
355 x 91 x 76 mm (L x W x H)
Net Weight
1.5 Kg
Gross Weight
2.4 Kg
